Optionally, disable the Host to Master Track Send to ensure only the split audio is audible.įigure (above): The Master Send is deselected AND Sidechain Sends are used for Send Tracks, to avoid the Main Out making it to the Master by either route. This prevents the audio from Frequency Splitters Main Output reaching the destination Mixer Tracks via that route. Use Sidechain Sends - For all Host Track to Destination Track links, use Sidechain sends.Do this in one of four ways (choose the method that best suits your preferred workflow): NOTE: If you want to use the Sends to split an audio signal for independent processing, you normally will need to prevent Frequency Splitters Main Output reaching the Send Tracks. Equalization curve (Visualization) - Display the resulting EQ curve for the Send output in response to Low, Mid and High level changes.Bands (Visualization) - Show the Low, Mid and High Send filter bands.Low, Mid, High (Knobs) - Send / Sidechain band level controls.NOTE: Naming Mixer tracks will make identifying the correct target Track easier. To use them, first send the Mixer Track hosting Frequency Splitter to additional Mixer Track/s then ( Left-Click) and drag or ( Right-Click) and directly select the target Mixer track (by name) from the pop-up list. Target mixer track (controls) - These integrate with the Mixer Track Send feature.That is, they will be audible on the destination Mixer Track, even if the host Mixer Track send is of type Sidechain or its fader is set to zero. Sends are Pre-Fader to the destination Mixer Track. Do this by creating links between the Host Mixer Track and the Destination Track/s you want to Send to. That is, destinations won’t be available until you have created Mixer Track sends from Frequency Splitters Host track to at least one other Mixer track. Sends - You can send the bands to any linked Mixer Track.Equalization curve (Visualization) - Display the resulting EQ curve for the Main output in response to Low, Mid and High level changes.Bands (Visualization) - Show the Low, Mid and High Main filter bands.Mute / Solo (Switches) - Below the knobs, use the switches to Mute ( Left-Click) or Solo ( Right-Click).Low, Mid, High (Knobs) - Band level controls.Main Output - Control band levels, mute or solo them.When the limits of the frequency range are encountered at either end, the gap will compress to minimum. Moving one will move the other by the same amount. Link (Icon) - When selected the movement of Low and High FREQ knobs are linked.In 2 band mode, the Low Cutoff Frequency controls for the Low/High frequency split point. Cutoff Frequency (Knobs) - Choose filter band Cutoff Frequencies between 30 Hz and 16 kHz for the Low and High Bands.
#Audio splitter online manual
The reason for all this detail is that manual writers are paid by the word. If you are at all confused, just look at the Equalization curves for the various settings (slopes). The slope you choose depends on the sound you want to achieve. 96 dB is extremely steep and will quickly filter frequencies past the cutoff. 6 dB is a very shallow slope, allowing many frequencies past the cutoff. Rather frequencies trail off to silence at a given rate, specified in dB ( decibels) per octave. NOTE: Filters do not instantly stop audio at their Cutoff Frequency.
#Audio splitter online how to
Once you understand how to route Frequency Splitter, a world of advanced signal processing awaits! The 'MAIN OUT' and 'SENDS' carry the same signals, so its easy to end up doubling your audio. NOTE: The most confusing aspect of Frequency Splitter is routing. Finally, the frequency response input and output display modes allow quick decision making, removing guesswork. Each band can be cut, boosted, muted and soloed, for precise monitoring and quick equalization.
A wide range of crossover slopes from 6 to 96 dB/Oct are available to suit all mixing tasks.
For example, Frequency Splitter is exceptionally useful in Patcher! Frequency splitter also offers zero latency, Minimum Phase crossovers, or high fidelity and responsive Linear Phase crossover filters, for perfect recombination with the dry or other signals. Bands may be routed to independent audio outputs for advanced multi-band effects processing.
Frequency Splitter allows you to separate audio into low and high, or low, mid, and high frequency bands.
